655nm Laser Module

Power (25°C): 1500W Wavelength Range: 1080±10nm Fiber Core Diameter: 20μm

The BFL-ACW20S-2 is a 1500W air-cooled fiber laser from BWT's Storm Series. It adopts a brand-new heat dissipation structure and powerful fans, delivering superior cooling performance and more stable laser operation. Its compact design offers greater freedom, rationality, and integration flexibility for laser equipment design. This air-cooled laser features excellent beam quality, allowing the laser beam to be focused close to the diffraction limit for precision processing. Both continuous wave (CW) and modulated pulse working modes are selectable, greatly reducing the heat-affected zone during processing. With reliable performance and a modular all-fiber design, all optoelectronic components are sealed inside a rugged enclosure. It can process various steels, aluminum and nickel-based alloys, titanium alloys, and alumina ceramics.

Power (25℃): 300W Wavelength Range: 1080±10nm Fiber Core Diameter: 14μm

The BWT Storm Series fiber laser BFL-ACW05S adopts a brand-new heat dissipation structure and powerful fans, delivering superior cooling performance and more stable laser operation. Its compact and minimalist enclosure design provides greater freedom, rationality, and high integration for laser equipment design. This air-cooled laser offers excellent beam quality, allowing the laser beam to be focused close to the diffraction limit for precision processing. Both continuous-wave (CW) and modulated-pulse operation modes are selectable, greatly reducing the heat-affected zone during processing. With reliable performance and a modular all-fiber design, all optoelectronic components are sealed inside a rugged enclosure. The laser can process various steels, aluminum-based and nickel-based alloys, titanium alloys, and alumina ceramics, and it is widely used in precision welding, precision cutting, handheld welding, and sheet metal processing. BWT also provides professional laser application engineers and high-quality laser system solutions.

Output Power (25℃): 500W Wavelength Range: 1080±10nm Fiber Core Diameter: 14μm

The BWT Storm series fiber laser adopts a brand-new heat dissipation structure and powerful fans, delivering superior cooling performance and more stable laser operation. Its simple and compact appearance design provides greater freedom for laser equipment design, with higher rationality and integration. This air-cooled laser features excellent beam quality: the laser beam can be focused close to the diffraction limit to achieve precision processing. Two operating modes (continuous wave and modulated pulse) are selectable, greatly reducing the heat-affected zone during processing. With reliable performance and a modular all-fiber design, all optoelectronic components are sealed inside a rugged housing. It is widely used in precision welding, handheld welding and sheet metal processing, and can process various steels, aluminum-based and nickel-based alloys, titanium alloys, alumina ceramics, etc.

Power (25℃): 800W Wavelength Range: 1080±10nm Fiber Core Diameter: 14μm

The BWT Storm series fiber laser adopts a brand-new heat dissipation structure and powerful fans, delivering superior cooling performance and more stable laser operation. Its compact appearance design provides greater freedom for laser equipment integration, with enhanced rationality and high integration. This air-cooled laser features excellent beam quality, allowing the laser beam to be focused close to the diffraction limit for precision processing. It offers both continuous-wave (CW) and modulated pulse working modes, greatly reducing the heat-affected zone during processing. With reliable performance and a modular all-fiber design, all optoelectronic components are sealed inside a rugged enclosure. It can process various materials including carbon steel, aluminum-based and nickel-based alloys, titanium alloys, and alumina ceramics.

Product Power: 10W Center Wavelength: 1030±2nm Repetition Frequency: 50MHz (Adjustable)

The BFL-1030-10LE is a high-power, narrow pulse width infrared femtosecond laser developed by Tianjin BWT Laser Technology Co., Ltd. (BWT), a national high-tech enterprise specializing in femtosecond, picosecond and nanosecond lasers. It delivers 10W average output power at a center wavelength of 1030±2nm with a 50MHz repetition rate (frequency adjustable), an adjustable pulse width of 200fs-2ps, and a maximum single pulse energy of 200nJ. Featuring TEM00 beam quality (M²<1.3), >90% beam circularity, vertical polarization (100:1), excellent power and pulse energy stability, intelligent real-time monitoring and a simple control interface, the laser is packaged in a compact air-cooled housing (L461.5 x W352.7 x H169.6mm) supporting 110V~260V AC power. It is a low-cost, maintenance-free ultrafast laser solution ideal for precision processing and scientific research.
