SWU901 Wall-mounted Ultrasonic Flowmeter
SWU901 is a real-time differential ultrasonic flowmeter. It measures flow rate by detecting the time difference between upstream and downstream ultrasonic signals, offering high accuracy without the need to break or modify pipes. The device is ideal for external installation, ensuring precise flow data acquisition.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Measuring Medium | Single acoustic liquid |
| Measuring Range | ±0.01m/s~±12m/s |
| Accuracy | 0.5% |
| Repeatability | 0.1% |
| Pipe Diameter | 25mm to 5000mm (Contact for products below 25mm) |
| Output | 4~20mA, max load 750Ω |
| Pulse Output | 0~9999Hz, OCT (min. and max. frequency adjustable) |
| Relay Output | SPST, max 1Hz (1A@125VAC or 2A@30VDC) |
| Communication | RS232&RS485 |
| Storage | TF card (expandable to 8G), data transmission every 60s, usable for 12 years |
| Power Supply | 90-245VAC, 48-63Hz or 10-36VDC |
| Display | 240×128 LCD |
| Operating Temperature | Transmitter: -40°F~140°F (-40°C~60°C); Sensor: -40°F~176°F (-40°C~80°C, standard type); 32°F~356°F (0°C~180°C, high-temperature type) |
| Measurement Environment | Relative humidity 0-99% |
| Protection Level | Transmitter IP65, Sensor IP68 |
| Cable | Dual-shielded cable, standard length 9m, extendable to 274m |
