SWU901 Wall-mounted Ultrasonic Flowmeter
SWU901 is a real-time differential ultrasonic flowmeter. It measures flow rate by detecting the time difference between upstream and downstream ultrasonic signals, offering accurate data without pipe cutting or interruption.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Measuring Medium | Single acoustic liquid |
| Accuracy | 0.5% |
| Repeatability | 0.1% |
| Pipe Diameter | 25mm to 5000mm (Contact for products below 25mm) |
| Pulse Output | 0~9999Hz, OCT (min. and max. frequency adjustable) |
| Relay Output | SPST, max 1Hz (1A@125VAC or 2A@30VDC) |
| Communication | RS232&RS485 |
| Power Supply | 90-245VAC, 48-63Hz or 10-36VDC |
| Display | 240×128 LCD |
| Measurement Environment | Relative humidity 0-99% |
| Cable | Dual-shielded cable, standard length 9m, extendable to 274m |
Applications
Key Features
Datasheet
Supplier Information
