LA Series Photodiodes
High-performance photodiodes designed for optical detection applications, offering excellent sensitivity and reliability.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Photosensitive Surface Diameter | Φ |
| Responsivity (A/W) LA50 | 0.95-1.05 |
| Responsivity (A/W) LA80 | 0.95-1.05 |
| Responsivity (A/W) LA200 | 0.95-1.05 |
| Responsivity (A/W) LA500 | 0.95-1.05 |
| Responsivity (A/W) LA1000 | - |
| Gain LA50 | 10-13 |
| Gain LA80 | 10-13 |
| Gain LA200 | 10-13 |
| Gain LA500 | 10-13 |
| Gain LA1000 | - |
| Maximum Gain LA50 | 30-35 |
| Maximum Gain LA80 | 30-35 |
| Maximum Gain LA200 | 20-35 |
| Maximum Gain LA500 | 20-35 |
| Maximum Gain LA1000 | 50 |
| Dark Current (nA) LA50 | - |
| Dark Current (nA) LA80 | - |
| Dark Current (nA) LA200 | 6-25 |
| Dark Current (nA) LA500 | 6-25 |
| Dark Current (nA) LA1000 | 50 |
| Dark Current Temperature Coefficient (times/°C) LA50 | - |
| Dark Current Temperature Coefficient (times/°C) LA80 | - |
| Dark Current Temperature Coefficient (times/°C) LA200 | 1.1 |
| Dark Current Temperature Coefficient (times/°C) LA500 | 1.1 |
| Dark Current Temperature Coefficient (times/°C) LA1000 | - |
| Capacitance (pF) LA50 | 2.0-2.5 |
| Capacitance (pF) LA80 | 2.0-2.5 |
| Capacitance (pF) LA200 | 10-15 |
| Capacitance (pF) LA500 | 10-15 |
| Capacitance (pF) LA1000 | - |
| -3dB Frequency (GHz) LA50 | 0.4-1.4 |
| -3dB Frequency (GHz) LA80 | 0.4-1.4 |
| -3dB Frequency (GHz) LA200 | 0.4-0.3 |
| -3dB Frequency (GHz) LA500 | 0.4-0.3 |
| -3dB Frequency (GHz) LA1000 | - |
| Breakdown Voltage (V) LA50 | 30-80 |
| Breakdown Voltage (V) LA80 | 30-80 |
| Breakdown Voltage (V) LA200 | 30-80 |
| Breakdown Voltage (V) LA500 | 30-80 |
| Breakdown Voltage (V) LA1000 | - |
| Breakdown Voltage Temperature Coefficient LA50 | 0.1-0.15 |
| Breakdown Voltage Temperature Coefficient LA80 | 0.1-0.15 |
| Breakdown Voltage Temperature Coefficient LA200 | 0.1-0.15 |
| Breakdown Voltage Temperature Coefficient LA500 | 0.1-0.15 |
| Breakdown Voltage Temperature Coefficient LA1000 | - |
