Photonics Source provides 45 products. Download datasheets, request quotes, and compare function, price, and availability.
-
Aspherical Lens
Focal Length: 3.3-8 Back Focal Length: 0.7-4.3 Diameter: 6-12.7 Center Thickness: 2.5-5.8 Edge Thickness: 0.6-2.1 -
Fused Silica Spherical Lens
Product Code: JLYS-L1000, JLYS-L1245, JLYS-L1250, JLYS-L1270, JLYS-L1500, JLYS-L2000, JLYS-L2500, JLYS-L3000, JLYS-L4000, JLYS-L5000, JLYS-L6000, JLYS-L7000, JLYS-L8000, JLYS-L10000, JLYS-L12000 Diameter (mm): 1.0, 1.245, 1.25, 1.27, 1.5, 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 10.0, 12.0 Diameter Tolerance (mm): ±0.002, ±0.005, ±0.01 Refractive Index: 1.4585 Effective Focal Length (mm): 0.79, 1.59, 2.39, 3.18, 3.98, 4.77, 5.57, 7.95 -
胶合透镜
Diameter(mm) JH004: 10 Thickness(mm) JH004: 3.5 Material JH004: H-LAF52/H-ZF1A Radius R1 JH004: 420-680 Radius R2 JH004: 155.5 -
Optical Lens
Diameter(mm): 2.4, 1.5, 3, 4, 4.5, 6.325, 5, 6.33, 5.42 Effective Focal Length(mm): 1.14, 1.85, 2.2, 2.73, 2.75, 3.1, 3.37, 3.76, 2.8, 2.41, 3.08 VD(mm): 1.129/4.826, 0.72, 0.88, 1.39, 1.09, 1.292, 1.513, 2.37, 1.75, 1.76, 2.09, 5.0/6.91, 2.98, 2.91, 2.8, 2.41, 3.08 Center Thickness(mm): 1.239, 1.24, 1, 1.1, 2, 1.685, 1.65, 1.426, 2.24, 3.214, 2, 2.5, 1.5, 2, 3.1, 2.8, 2.41 NA: 0.43/0.124, 0.55, 0.56, 0.32, 0.5, 0.55, 0.5, 0.55, 0.64, 0.67, 0.37, 0.31/0.23, 0.33, 0.5, 0.47 -
Optical Lenses
Diameter: Customizable Effective Focal Length (EFL): Customizable Edge Thickness (Te): Customizable Center Thickness (Tc): Customizable Radius of Curvature (R1): Customizable -
Optical Lens
Diameter: -0.05-0.1mm Radius of curvature: R1, R2 Central thickness: +/-0.02 Edge thickness: TE Principal point: H' -
Plano-Concave Lenses
Diameter: 12mm, 15mm, 16mm, 26mm, 23mm, 15.15mm, 13.2mm, 20mm, 31mm, 19mm Thickness: 1.1mm, 2.5mm, 1.3mm, 1.53mm, 1.25mm, 1.62mm Material: H-ZF7LA, ZF6, H-K9L, F1 [CDGM] Radius of curvature: 0, 19.474, 12.7, 11.695, 51.68, 11.86 Wavelength Range: 400-700nm, 420-760nm, 405nm, 550nm, 660nm -
Optical Lens
Material: Optical-grade glass Diameter: Customizable Focal Length: Customizable Surface Quality: 40/20 scratch-dig Coating: Anti-reflective coating -
Double Concave Lens
Diameter(mm): 11, 11.9, 12, 30, 40, 60, 70 Thickness(mm): 1.6, 1.03, 0.95, 3, 2, 6, 1.8 Material: F2, H-ZK11, H-K9L Radius R1(mm): 16.6, 86.238, 25.1, 104.25, 104.25, 45, 15.0809 Radius R2(mm): 43.26, 21.727, 25.1, 104.25, 104.25, 45, 124.987 -
Precision Optical Lens
Diameter: 9mm(-0.05mm) Center Thickness: 3mm(±0.05mm) Radius of Curvature R1: 39.6 Radius of Curvature R2: 39.6 Effective Focal Length: 38.81mm -
Precision Optical Lens
Diameter: 70mm(-0.05mm) Center Thickness: 17mm(±0.05mm) Radius of Curvature R1: 100.72 Radius of Curvature R2: 100.72 Effective Focal Length: 100mm -
Precision Optical Glass Lens
Diameter: 52mm (-0.05mm) Center Thickness: 6.8mm (±0.05mm) Radius of Curvature R1: 453 Radius of Curvature R2: 149 Effective Focal Length: 217mm -
Precision Optical Lens
Diameter: 50mm (-0.05mm) Center Thickness: 8.6mm (±0.05mm) Radius of Curvature R1: 97.22 Radius of Curvature R2: 97.22 Effective Focal Length: 95.5mm -
Plano-Convex Lens
Diameter: 50.8mm Center Thickness: 11.8mm Radius of Curvature: 75.20 Edge Thickness: 3mm Effective Focal Length: 75mm -
Plano-Convex Lens
Diameter: 50.8mm Center Thickness: 3.8mm Radius of Curvature: 771.99 Edge Thickness: 3mm Effective Focal Length: 750mm -
Plano-Convex Lens
Diameter: 50.8mm Center Thickness: 4.3mm Radius of Curvature: 514.36 Edge Thickness: 3mm Effective Focal Length: 500mm -
Plano-Convex Lens
Diameter: 50.8mm Center Thickness: 4.6mm Radius of Curvature: 411.29 Edge Thickness: 3mm Effective Focal Length: 400mm -
Plano-Convex Lens
Diameter: 50.8mm Center Thickness: 5.1mm Radius of Curvature: 308.29 Edge Thickness: 3mm Effective Focal Length: 300mm -
Plano-Convex Lens
Diameter: 50.8mm Center Thickness: 5.5mm Radius of Curvature: 256.61 Edge Thickness: 3mm Effective Focal Length: 250mm -
Plano-Convex Lens
Diameter: 50.8mm Center Thickness: 6.6mm Radius of Curvature: 179.15 Edge Thickness: 3mm Effective Focal Length: 175mm
