Fibre-optic coupling/decompositioners

Model@FiberType: fiber Installation@Installation: 118×29.2(2-Φ6)

⚫ High Return Loss;

Low PDL;

⚫ High Isolator;

Combination efficiency: ≥70% Valid focal length: Customise Transminal Type: 350-700nm、600-1050nm、1050-1620nm

Multi-axis fibre-optic couplings regulate the design through high precision five-axis; maintain the interface and fibre-optics in motion; align the positions of the inner lenses X and Y, respectively; and align the Z-axis orientations with the angles of the Z-axis based on the three Z-axis regulators; and meet the user ' s laser alignment/associate straightness functional needs. The overall structure is compact; it is easy; it is heat-stabilized; it is high resolution-to-structure; it is suitable for long-term or short-term alignment/precision. In addition; the position of the K key at the fibre-optic interface can be reconciled with three fixed screws of screwdrivers; and the alignment of the fibre-optics for protection purposes. The locks on the Z-axis adjuster can be locked by locking the wrench; fixed lenses can be leaned over and tilted at an angle. The panel position contains a tight screw with an X/Y axis regulator; the X/Y axis regulator can be fined up by the adjustment tension. X/Y axle adjuster with a lock screw on the side X/Y axle; normally without locking; if in a larger vibration and impact environment; if a lock screw lock is required Tight
