T01 human eye safety laser launch antenna
The T01 series of human eye-safe laser-launching antennas; an integrated laser module consisting of passive Q-ray lasers of the apricot pump, developed autonomously by almonds, with the launch antenna, optical detectors (PD); and specialized applications in laser ranging, laser remote sensing, laser radar. The module produces 1535 nm human eye safety wavelength lasers; provides laser synchronous signals; has small size, small dispersive angles, wide temperature work, etc
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Launch antenna pass rate | >90% |
| Repeat frequency | 10Hz |
| Energy stability | 3% |
| Photogram Size | 9mm |
| All over the corner | ≤0.5mrad |
| Beam Mode | TEM00 |
| @PD typ | 3V |
| Weight | 13.5g |
| Wavelength | 1535nm |
| Laser single pulse energy | 100; 200; 300μJ |
