R4MH High Power Semiconductor Laser Model
R4MH is a multi-functional AW series of apricots and semiconductors; multi-wave-length output; integration of four different wavelengths of primary lasers; fibre-optic extraction design; configuration of fibre-optic switches, PD PV detectors, RT thermal sensitivity resistance, etc
Request a Quote
Download Datasheet
Overview
R4MH is a multi-functional AW series of apricots and semiconductors; multi-wave-length output; integration of four different wavelengths of primary lasers; fibre-optic extraction design; configuration of fibre-optic switches, PD PV detectors, RT thermal sensitivity resistance, etc
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 4; 0.5; 10W |
| He's on the wavelength | ±10nm |
| spectral width | <6nm |
| Wave length with temperature properties | 0.3nm/°C |
| Microefficiency | 1.3; 0.7; 0.9; 0.8 / 0.8W/A |
| Electricity | <8000μA |
| Heat-sensitive electrical resistance parameters | 10±1%/3930 |
| Fibre-pack diameter | 440μm |
| Fibre coating diameter | 720μm |
| Numerical aperture | 0.22 |
| Connector | SMA905 |
| Central wavelength | 450; 650; 808; 9XX / 1064nm |
Applications
Spectrum detection; biomedical; material analysis; display of lighting; laser manufacturing
Key Features
Light spots are even; power is stable; heat spread is good; reliability is high; different wavelength output is available
Datasheet
Product Datasheet
PDF
Supplier Information
Beijing RealLight Technology Co., Ltd. was founded in 2010 and is a high-tech enterprise specializing in the independent research and development, production, and sales of semiconductor lasers, microchip lasers, erbium glass lasers, high-power solid-state lasers, high-energy lamp-pumped lasers, and supporting components.
The company has a large and innovative engineering and technical team. After years of technical accumulation and process precipitation, RealLight has gained professional capabilities in laser design, chip packaging, device packaging, system integration, etc., and has successfully completed a number of technological innovation projects and model equipment projects, and has obtained multiple qualification certifications, patent works, and product certifications.
We have provided many innovative and competitive products to customers in various fields such as analytical instruments, biomedical, radar ranging, laser processing, etc. At the same time, we can also provide customized overall solutions and high-quality services according to customer needs.
RealLight looks forward to becoming your partner and creating value for you with laser technology!
