R3F High Power Semiconductor Laser Models
R3F is the Apricotian Wisdom Semiconductor AW Series laser module; a single wavelength output; capable of integrating 3 primary wavelength lasers; fibre-optic coupling output design; high reliability features with power stability, even light spots
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 20; 30W |
| He's on the wavelength | ±10nm |
| spectral width | <6nm |
| Wave length with temperature properties | 0.3nm/°C |
| Microefficiency | 2.1; 2.5W/A |
| Fibre-pack diameter | 220μm |
| Fibre coating diameter | 400μm |
| Fibre length | 100±10cm |
| Numerical aperture | 0.22 |
| Connector | SMA905 |
| Central wavelength | 808; 980; 1064nm |
