R2T double wavelength narrow line wide semiconductor laser module
The R2T containment module is a star product of the apricot-wise NL narrow-width laser product line; the product is capable of producing two wavelengths at the same time; applies to differential absorption of Laman; based on VBG lock wave technology; co-opts with TEC; achieves stable power output and high border depressive ratio; has good temperature wavelength drifting properties
Specification Snapshot
Maximum voltage
6.7V
Request a Quote
Download Datasheet
Overview
The R2T containment module is a star product of the apricot-wise NL narrow-width laser product line; the product is capable of producing two wavelengths at the same time; applies to differential absorption of Laman; based on VBG lock wave technology; co-opts with TEC; achieves stable power output and high border depressive ratio; has good temperature wavelength drifting properties
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 600/600; 500/800mW |
| He's on the wavelength | ±0.5nm |
| spectral width | <0.1nm |
| Wave length with temperature properties | 0.01nm/°C |
| Microefficiency | 0.7W/A |
| Electricity | <2000μA |
| Heat-sensitive electrical resistance parameters | 10±1%/3450 |
| Maximum voltage | 6.7V |
| Fibre-pack diameter | 125μm |
| Fibre coating diameter | 250μm |
| Fibre length | 100±10 (other lengths customizable)cm |
| Numerical aperture | 0.22 |
| Connector | FC/PC, SMA905 |
| Laser laser center wavelength | 784.5/785.5; 785/1064nm |
Applications
Spectrospectral analysis; medical applications; scientific applications
Key Features
Structure compact; output stable; high reliability
