HQF series of light pump leather seconds lasers
The HQF series of light pump MOPA skin second lasers are designed with a single lamp double-stick; they consist of MC series micro-filter, RL-ISO series separators, and light pump laser amplifiers; they are optionally equipped with internal light gates and energy detectors. The products in this series are energy-high, narrow, stable and luminous; wavelengths cover 1064 nm and 532 nm; and can be widely used in the biomedical industry, such as in the areas of tattooing, plastering and skin. Parts
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Frequency | 1~10Hz |
| Energy | 500mJ@1064nm, 250mJ@532nm; 400mJ@1064nm, 200mJ@532nm |
| Energy stability | <2%@1064nm, <3%@532nm; <3%@1064nm, <4%@532nm |
| Pulse width | 350; 400ps |
| Horizontal Full-Angle Divergence (1/e²) | <3mrad |
| Vertical Full-Angle Divergence (1/e²) | <3mrad |
| Luminous diameter | ~11mm |
| Luminous Mode | Flattop |
| Distortion | Straight |
| Electricity requirements | 220V/110V±10%AC, 50/60Hz |
| Operational environmental requirements | Temperature 10-30°C, humidity < 75% |
| Wavelength | 1064 / 532nm |
