GS16 Cool Vertical Array
GS16 Transmitting the cooling vertical array is a device developed by almonds with light and applied in a wide temperature range. It has high peak power, small size and easy integration characteristics
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Central wavelength range | ±5; ±3nm |
| Each output power | 100; 200W |
| Laser Bar Count | 1~2; 1~5; 1~3 |
| Space | 0.8; 0.43; 0.55mm |
| spectral width | ≤5nm |
| Quick-axis split | 40 |
| Slow-axis Shape | 10 |
| Wave temperature drift factor | ~0.3nm/°C |
| Central wavelength | 940; 790~812nm |
| Electricity conversion efficiency | ≥50% |
| Every working voltage | ≤2.1V |
| Percentage | ≤1.5%@200W; ≤0.6%@500W; ≤0.6%@600W |
| Repeat frequency | 1~5; 1~20Hz |
| Working temperature range | -40~65℃ |
Applications
Key Features
