Conical Magnifying Laser
The LAPIS series conical amplification laser system consists mainly of semiconductor laser sources, conical amplifiers, space light separators, beam-specific straight-forming modules, precision current sources and temperature control systems; core components are conical amplifiers; power amplifiers are expanded for input-based semiconductor laser sources; and physical properties such as polarization, linear width and frequency of seed light are maintained. The product integrates active power sta
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Work wavelength | 670-1550 nm (customable) |
| Harmonizing Range | ± 1 nm (consistent with seed light) |
| Width | ≤1 MHz (consistent with seed light) |
| Power stability | ≤0.1%@8hrs |
| Wavelength stability | ≤50 MHz@8hrs |
| Border Model Impression Ratio | ≥35 dB |
| Fibre coupling | Single model, 70% coupling efficiency |
Applications
Key Features
Datasheet
