Active stabilization power module
The LAPIS-series Active Stable Power Module is a laser power lock-in module designed on the basis of acoustic PV (AOM). In the course of their use, only stable lasers will be required to be entered into QTM-APS; pass through PID algorithms; set target photopower and corresponding calibration parameters (e.g. PI parameters); this module will complete the active control of laser power; ensure the stability of laser power; effectively contain the fluctuations in laser output power; and is an ideal
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Work wavelength | 440-950nm |
| Maximum output efficiency | 50% |
| Power stability | ≤0.1%@8hrs |
| Power voltage | 24V |
| Up and down | 30ns |
| Laser Input Method | Fibre input |
| Laser Output Method | Fibre-optic output/space-light output |
Applications
Key Features
Datasheet
