variable aperture
• Continuously variable • Can be connected to external rods • Black anodized aluminum alloy housing to limit reflection • Customization services and solutions are provided. An aperture stop is an entity that limits the beam in an optical system. It can be the edge of a lens, a frame or a specially set perforated screen. Its function has two aspects: limiting the beam or limiting the size of the field of view (imaging range). In optical experiments, point light sources or controlled light throughput are often needed, which can be achieved using an aperture stop with continuously adjustable aperture. Our company's adjustable aperture stops have many blades, smooth apertures, continuous adjustability, and are compact, attractive and very convenient to use. The greatest advantage of using an adjustable aperture stop for spatial filtering is that the size of the central opening can be continuously adjusted, making it easier to let some frequency components on the spectrum plane pass while blocking other frequency components, thereby changing the frequency components of the image on the image plane.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Aperture | 1.5μm |
| Mounting Base | None |
Applications
Key Features
Datasheet
Please provide your email to download the datasheet.
