SP920nm Shortpass Filter
Specification 920nm Shortpass Filter: IAD Peak Transmittance: 70%~90%( ) Bandwidth: 30nm~100nm Band: 200nm~1100nm ( ): T<0.01%,T<0.1%,T<0.5%( ) Product Material: (K9, BK7, B270, D2
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Bandwidth | 30nm~100nm |
| Band | 200nm~1100nm ( ) |
| Product Material | (K9, BK7, B270, D263T, Quartz, ) |
| Product Thickness | 0.35mm,0.6mm,0.8mm,1.1mm,2.0mm,3.0mm,4.0mm |
| Process method | IAD multi-layer dielectric dura mater |
| cutoff depth | T<0.01%, T<0.1%, T<0.5% (according to customer needs) |
| Square | Ф4mm,Ф10mm,Ф12mm,Ф15mm,Ф20mm,Ф25mm,Ф30mm,Ф50mm |
| round | 22mm,44mm,6.56.5mm,88mm,1010mm,1212mm,2525mm,7070mm |
