2.5Gbps InGaAs APD Photodiode Chip

2.5Gbps InGaAs APD Photodiode Chip

Supplier
Ovqt-Vital
Part Number
2.5Gbps InGaAs APD Photodiode Chip
Category
Photodiodes
Origin
China

The 2.5Gbps APD chip is a front-illuminated planar bare die with opposite-side

Specification Snapshot
Dark Current - Test Condition: Vr=Vbr-3
Max 1nA
Responsivity - Test Condition: 1550nm, 1uW, M=1
Min 0.9A/W; Typ 1A/W
Gain - Test Condition: Vr=Vbr-1
Min 30
Gain - Test Condition: Vr=Vbr-2
Min 20
Gain - Test Condition: Vr=Vbr-3
Min 10
-3 dB Bandwidth - Test Condition: Vbr-1
Min 2GHz
Request a Quote Download Datasheet
Save to Favorites Save to Favorites

Overview

The 2.5Gbps APD chip is a front-illuminated planar bare die with opposite-side PN electrodes, high bandwidth, high responsivity and high reliability.

Specifications

ParameterValue
Reverse Breakdown Voltage - Test Condition: Id=10uA,no illumination35~50V
Dark Current - Test Condition: Vr=Vbr-3Max 1nA
Responsivity - Test Condition: 1550nm, 1uW, M=1Min 0.9A/W; Typ 1A/W
Gain - Test Condition: Vr=Vbr-1Min 30
Gain - Test Condition: Vr=Vbr-2Min 20
Gain - Test Condition: Vr=Vbr-3Min 10
-3 dB Bandwidth - Test Condition: Vbr-1Min 2GHz
-3 dB Bandwidth - Test Condition: Vbr-3Min 2GHz
Breakdown Voltage Temperature Coefficient - Test Condition: -40°C~+85°C, Ir=10uATyp 0.12V/℃
Capacitance - Test Condition: Vr=Vbr-3, f=1MHzTyp 0.5pF

Applications

1. fiber optic communications, OTDR instruments and modules 2. optical network units 3. scanning imagers and related equipment

Key Features

1. 50um photosensitive area 2. high responsivity and low dark current 3. 2.5GHz high bandwidth
