Home All Products Imaging Infrared Imaging Uncooled Thermal Camera Core

Infrared Imaging

Uncooled Thermal Camera Core

Supplier

Ulirvision

Part Number

TC388G

Overview

TC388G|TC688G series components adopt imported high-quality durable shields, which are stable and durable, with clear images, and can be used in various harsh environments; this movement is suitable for the integration and secondary development of infrared thermal imaging systems that are not very sensitive to space.

Specifications

Parameter	Value
	Amorphous silicon
	17μm
	7.5~14μm
	≤70mK
	35mm, 50mm, 75mm athermal lens, 100mm, 150mm electric lens, 25~100mm, 30~150mm, 25~225mm continuous zoom lens, 60/150mm dual field of view lens and other lenses are optional
	IVE image enhancement algorithm
	50Hz
	black hot/white hot
	3s
	electric
	Switchable
	Yes
	40pin
	RS232
	PAL
	Default LVCMOS, Cameralink optional
	4 buttons
	DC: +4V~+5.5V (5V standard)
	1.5W
	Yes
	Yes
	5%~95% (non-condensing)
	GJB150-16 2.3.1, 100g; 6msec
	GJB150-16 2.3.1, 4.3g 3-axis, 8h
	44.5mm×44.5mm×39.5mm
	4 M2×0.4, 1/4”-20
	Default LVCMOS, Cameralink optional

Applications

Security thermal imaging camera; thermal imaging pan/tilt; small ship-mounted; vehicle-mounted; remote aiming system

Key Features

17μm pixel spacing, NETD<60mK; 50Hz real-time video, 3S instant start; ≤1.5W low power consumption; IVE image enhancement algorithm, clear imaging; customizable interface
