TruLaser Series
The TruLaser Series offers advanced laser cutting solutions designed for precision and efficiency in industrial applications. With features like intelligent automation, high-speed cutting, and robust operation, these machines are ideal for diverse manufacturing needs.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Maximum Format Size X-Axis (mm) | 3000-8000 |
| Maximum Format Size Y-Axis (mm) | 1500-2500 |
| Maximum Format Size Z-Axis (mm) | 116 |
| Max Weight (up to 6kW) (kg) | 900-7850 |
| Max Weight (9kW and higher) (kg) | 1800-7850 |
| Max Speed Simultaneous (m/min) | 140-170 |
| Mean Bidirectional Positioning Error M (mm) | 0.05-0.06 |
| Bidirectional Positioning Error A (mm) | 0.06-0.07 |
| Available Lasers | TruFiber 4000/6001/9001/12001/24001 |
| Max Power (W) | 4000-24000 |
| Wavelength (nm) | 1080 |
| Max Sheet Thickness Structural Steel (mm) | 20-60 |
| Max Sheet Thickness Stainless Steel (mm) | 20-50 |
| Max Sheet Thickness Aluminum (mm) | 15-40 |
| Max Sheet Thickness Copper (mm) | 10-16 |
| Max Sheet Thickness Brass (mm) | 10-12.7 |
| Average Power Consumption During Production (kW) | 10-27 |
Applications
Key Features
Datasheet
Supplier Information
Related Products
-
TruLaser Series
Fiber Optics
Trumpf
Maximum Format Size X-axis(mm) TruLaser 1030 Lean Edition: 3000 Maximum Format Size Y-axis(mm) TruLaser 1030 Lean Edition: 1500 Maximum Format Size Z-axis(mm) TruLaser 1030 Lean Edition: 116
TruLaser Series offers advanced laser cutting solutions with high precision, efficiency, and flexibility, suitable for various industrial applications.
-
