Type 8007 Flowmeter for Gases
This flowmeter is designed for measuring large flow rates of gases using the calorimetric principle. It features a heated sensor element cooled by gas flow, providing accurate flow indication based on velocity and gas characteristics.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Material Seal | NBR, FKM (for oxygen) |
| Material Body | Standard variant: stainless steel 1.4301/304, heavy duty variant: stainless steel 1.4571/316Ti |
| Material Electronics Housing | Standard variant: polycarbonate, heavy duty variant: die-cast aluminium |
| Probe Length | Standard variant: 220mm, other lengths on request |
| Nominal Flow Range | Up to 44,030Nm³/h (air) |
| Maximum Operating Pressure | Standard variant: max. 16bar, optionally up to PN40; Heavy duty variant: max. 50bar |
| Measuring Accuracy | ±1.5% of reading ±0.3% FS |
| Measuring Span | 1:50 |
| Operating Voltage | 18...36V DC |
| Power Consumption | 5W |
| Output Signal | 4...20mA |
| Maximum Load | 500Ω (current output) |
| Operating Medium | Air |
| Operating Medium | nitrogen |
| Operating Medium | oxygen |
| Operating Medium | natural gas |
| Operating Medium | methane |
| Operating Medium | argon |
| Calibration Medium | Air |
| Operating Temperature | -30°C...+110°C (higher temperatures on request) |
| Communication Interfaces | Modbus RS485/RTU |
| Port Connection | G½" (other connections on request) |
| Degree of Protection | IP65 |
| Ambient Temperature | -30°C...+80°C (higher temperatures on request) |
