Crystal 12 Sensor
The INFICON Crystal 12 Sensor is designed for processes requiring continuous rate control, offering secure and automatic crystal replacement for extended operations.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Maximum Bakeout Temperature (No Water) | 130°C |
| Maximum Operating Isothermal Environment Temperature (Minimum Water Flow) | 300°C |
| Size (Maximum Envelope) | 4.0in(102mm)dia.x3.3in(84mm)high |
| Size (Maximum Envelope with Mounting Posts) | 4.75in(121mm)x3.46in(88mm) |
| Water and Air Length | 30in(762mm) |
| Crystal exchange | Front-loading |
| Weight | 4.92lb(2.23kg) |
| Installation Requirements - Feedthrough | Qty(1)2-3/4in.ConFlatwithonecoaxialfeedthrough,twopasswater,oneair,IPN750-685-G1;Qty(1)750-685-G2,withonecoaxialfeedthroughthreetubeUltra-Torrcompressionfittings;Qty(1)1in.boltwithonecoaxialfeedthrough,twopasswater,oneairIPN750-030-G1 |
| Installation Requirements - Mounting | User to provide mounting structure adequate to support weight of Crystal 12 |
| Air and Water Connections | User to provide vacuum-tight braze joints or connectors for the water and air tubes |
| Minimum Water Flow | 150-200cc/min |
| Coolant Temperature | 30°C max |
| Regulated Air Supply | 80-90PSIG(5.5-6.2bar) |
| Regulated Air Supply Unit | 550kPa-620kPa |
| Materials - Plate, Mechanical Parts, Body and Carousel | 304 type stainless steel |
| Materials - Springs, Electrical Contacts | Au plated Be-Cu, Au Plated 302 stainless steel |
| Materials - Water and Air Tubes | S-304,0.125in(3.2mm)O.D.x0.016in(0.4mm)WallThicknessx30in(762mm) |
| Connector | Stainless steel |
| Insulators | Teflon |
| Insulators | Peek |
| Cable | Teflon insulated copper plated steel |
| Crystal Diameter | 0.550in(13.97mm) |
