Fusion Splicer
A high-performance fusion splicer designed for efficient and precise fiber optic splicing, suitable for various fiber types and applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Electrode Life | 3000次 |
| Battery Capacity | 5200mAh (熔接 and 加热200次) |
| Input Voltage | DC11.1V |
| Charging Input | AC100-240V, 50/60Hz |
| Charging Output | DC13.5/4A |
| Splicer Dimensions | 191*141*119mm |
| Toolbox Dimensions | 5V/500mA |
| Weight (Without Battery) | 1.5KG |
| Weight (With Accessories) | 4.46KG |
| Operating Temperature (°C) | -15~50 |
| Operating Humidity | ≤95%RH (不结露) |
| Operating Wind Speed | ≤15m/s |
| Storage Temperature (°C) | -40~80 |
| Storage Humidity | 0~95% |
| Battery Temperature (°C) | -20~30 |
| Applicable Fiber | SMF(G.652)/MMF(G.651)/DSF(G.653)/NZDSF(G.655) |
| Fiber Diameter | 包层:80-150um;涂覆层:0.1-3mm |
| Splicing Loss | 0.02dB(SMF)/0.01dB(MMF)/0.04dB(DSF/NZDSF) |
| Alignment Method | 纤芯, 包层 |
| Focusing Method | 四马达 |
| Splicing Method | 自动/半自动/手动 |
| Splicing Time | 8秒(SMF典型值) |
| Tensile Test | 1.96-2.25N |
| Image Display | 电容式5寸触摸液晶屏 |
| Magnification | 300(X/Y)/150(X/Y同步) |
| Splicing Records | 10000组数据 and 1000张Image |
| Typical Heating Time | 18S(时间可选) |
| Heating Time | 0-60S |
| Heat Shrink Tubes | 20mm/30mm/40mm/50mm/60mm |
| Operation Interface | GUI图形化用户操作界面 |
