AQ4280 Optical Light Source
The AQ4280 Optical Light Source is a high-performance device designed for precise optical testing and measurement. It offers stable wavelength output and is suitable for various fiber optic applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength Range | 1310/1490/1550/1625nm |
| Light Source Type | LD |
| Compatible Fiber Type | SM (ITU-T G.652), optical fiber |
| Spectral Width | <5nm (1310nm), <5nm (1490nm), <5nm (1550nm), <5nm (1625nm) |
| Optical output level | -5dBm±0.5dB |
| Modulation Mode | CW, CHOP270Hz, 1kHz, 2kHz |
| Optical connector | FC |
| Optical connector | SC |
| Optical connector | ST |
| Power Supply | Dry and Rechargeable Battery AAA |
| Battery Life | Approximately 35 hours |
| Environmental Conditions | Operating temperature range: -10°C to 50°C, Storage temperature range: -20°C to 60°C (no condensation), Storage humidity range: 5%-95% (no condensation) |
| Pollution Degree | Pollution degree 2 |
| Dimensions and Weight | Approx. 300g |
| Laser Class | Class 1 (EN 60825-1:2014+A11:2021, IEC 60825-1:2014, 21 CFR 1040.10) |
