AQ2200 Series
The AQ2200 Series is a versatile measurement system designed for evaluating optical devices and optical transmission systems. It offers various measurement modules, including light sources, tunable lasers, optical power meters, optical attenuators, and optical switches.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength | 1310nm±5nm, 1550nm±5nm, 1625nm±5nm, 1650nm±5nm |
| Power Stability | ±0.005dB |
| SMSR | >40dB |
| Insertion Loss | ≤0.1dB |
| Optical Power | +10dBm |
| Fiber Type | SMF/10/125μm, MMF/50/125μm, MMF/62.5/125μm |
| Frequency Range | 196.25-191.50THz (1527.60-1565.50nm), 100GHz, 50GHz, 25GHz |
| Frequency Accuracy | ±0.1GHz@typ±8pm@1550nm, ±0.2GHz@typ±16pm@1550nm |
| Frequency Stability | ±0.3GHz@typ±24pm@1550nm, ±0.3GHz@typ±2.4pm@1550nm |
| Power Range | 0~280W |
| Power Uncertainty | ±2.5% |
| Detector Diameter | InGaAs: 5mm, Si: 5.8mm |
| Switch Repeatability | ±0.01dB |
| Switch Isolation | ≥50dB |
| Switch Insertion Loss | ≤0.08dBp |
| Switch Fiber Type | SMF/ITU-T G.652, MMF/GI50/125, MMF/GI62.5/125 |
| Voltage Range | -7.5V~+5.25V |
| Current Range | 0~3A |
| Resolution | 0.01V, 0.01A, 0.1W |
