MAZ12-0X-1TP
The MAZ12-0X-1TP is a high-precision optical zoom lens designed for industrial imaging applications. It features a compact design, excellent optical performance, and compatibility with various sensors.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Working Distance (mm) 0.25x | 380(F)253-360 |
| Working Distance (mm) 0.5x | 180(F)147-180 |
| Working Distance (mm) 0.75x | 94(F)84-94 |
| Working Distance (mm) None | 49(F)45-49 |
| Working Distance (mm) 1.5x | 43(F)40-43 |
| Magnification (X) 0.25x | 0.09-0.56 |
| Magnification (X) 0.5X | 0.18-1.13 |
| Magnification (X) 0.75x | 0.27-1.69 |
| Magnification (X) None | 0.36-2.25 |
| Magnification (X) 1.5x | 0.45-2.81 |
| Magnification (X) 2.0X | 0.90-4.50 |
| Numerical Aperture (NA) 0.25x | 0.008-0.022 |
| Numerical Aperture (NA) 0.5X | 0.017-0.043 |
| Numerical Aperture (NA) 0.75x | 0.026-0.065 |
| Numerical Aperture (NA) None | 0.035-0.088 |
| Numerical Aperture (NA) 1.5x | 0.044-0.129 |
| Numerical Aperture (NA) 2.0X | 0.090-0.257 |
| Resolution (μm) 0.25x | 39.6-15.2 |
| Resolution (μm) 0.5X | 19.8-6.6 |
| Resolution (μm) 0.75x | 13.2-5.06 |
| Resolution (μm) None | 9.9-3.8 |
| Resolution (μm) 1.5x | 6.6-2.54 |
| Resolution (μm) 2.0X | 4.9-1.9 |
| Depth of Field (mm) 0.25x | 13.8-1.6 |
| Depth of Field (mm) 0.5X | 6.7-0.41 |
| Depth of Field (mm) 0.75x | 3.2-0.25 |
| Depth of Field (mm) None | 2.1-0.13 |
| Depth of Field (mm) 1.5x | 1.6-0.07 |
| Depth of Field (mm) 2.0X | 1.0-0.04 |
| Field of View (1/3") H | 3.6 |
| Field of View (1/3") V | 4.8 |
| Field of View (1/3") D | 6 |
| Field of View (1/2") H | 4.8 |
| Field of View (1/2") V | 6.4 |
| Field of View (1/2") D | 8 |
| Field of View (2/3") H | 6.6 |
| Field of View (2/3") V | 8.8 |
| Field of View (2/3") D | 11 |
