MT Series Telecentric Lens
The MT Series Telecentric Lens is designed for high-precision imaging applications, featuring coaxial illumination and a working distance of 65mm. It offers magnification options ranging from 0.5X to 6X, ensuring excellent resolution and depth of field.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Magnification | 0.5X, 0.8X, 1X, 1.5X, 2X, 2.5X, 3X, 4X, 5X, 6X |
| Working Distance (mm) | 65, 65.7, 63.7, 63.5, 63.5, 63.5, 63.5, 63.5, 63.5, 65 |
| Numerical Aperture | 0.026, 0.042, 0.045, 0.045, 0.045, 0.045, 0.045, 0.045, 0.045, 0.045 |
| Resolution (μm) | 12.8, 8.4, 7.5, 5.4, 3.8, 3.2, 2.8, 2.1, 1.6, 1.3 |
| Depth of Field (mm) | 3, 2, 0.88, 0.42, 0.24, 0.18, 0.15, 0.11, 0.08, 0.06 |
| Effective FNO | 9.5, 9.9, 11, 12, 13.5, 15, 15.5, 17, 18.5, 26.7 |
| Object/Image Distance | 174.8, 158.18, 170.5, 159.5, 160.8, 164.3, 173.05, 185.9, 207.6, 224.5 |
| TV Distortion | 0.01%, 0.02%, 0.02%, 0.02%, 0.02%, 0.02%, 0.02%, 0.02%, 0.02%, 0.02% |
| Max Sensor Size | 2/3 |
