bizhub 7223i/7221i
The bizhub 7223i/7221i is a high-performance black-and-white multifunction printer designed for efficient office use. It features advanced printing, scanning, and copying capabilities, making it ideal for modern workplaces.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Type | Black-and-white multifunction printer |
| Print Speed | 7223i: 23 pages/min, 7221i: 21 pages/min |
| Print Resolution | 600dpi |
| Memory Capacity | 2GB |
| Max Original Size | A3 (11"×17") |
| Scan Resolution | 600dpi |
| Paper Capacity | 350 sheets |
| Paper Weight | 64-157g/m² |
| Warm-up Time | 21 seconds |
| Interface | USB2.0, Ethernet 10/100/1000Base-T |
| Supported Operating Systems | Windows Server 2008 SP2/2012/2016, Windows 7/8.1/10 |
| Dimensions (W×D×H) | 627×615×458mm |
| Weight | 32kg |
| Max Power | 1522W |
| Scan Formats | TIFF |
| Scan Formats | |
| Scan Formats | Compact PDF |
| Scan Formats | JPEG |
| Scan Formats | XPS |
| Scan Formats | Compact XPS |
| Scan Formats | pptx |
| Scan Formats | Page setting |
| Fax Speed | 2.4kbps-33.6kbps |
| Fax Protocol | MH |
| Fax Protocol | MR |
| Fax Protocol | MMR |
| Fax Protocol | JBIG |
| Fax Resolution | Standard/Ultra-fine |
| Fax Size | A3, A4, A5 |
