AccurioPress C14010/C14010S and AccurioPress C12010/C12010S
AccurioPress C14010/C14010S and AccurioPress C12010/C12010S are high-performance digital printing systems designed to meet the demands of high-quality and high-volume printing. They offer advanced automation, reliable performance, and sustainable design, making them ideal for businesses seeking efficiency and productivity.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Resolution | 3600×2400dpi |
| Printing Speed | 140页/分钟 (A4) |
| Duty Cycle | 250万页 (A4) |
| Paper Size | 139.7mm-330.2mm×139.7mm-1300mm |
| Supported Media Weight | 52-450g/m² |
| Main Unit Dimensions | 1151×932×1620mm |
| Main Unit Weight | 550kg |
| Power Requirements | 220V, 48A, 50/60Hz |
| Controller Type | Fiery IC-322, Creo IC-320 |
| Storage | SSD: 48GB, HDD: 4TB |
| Processor | Intel Core i7-10700 |
| Operating System | Linux |
| Supported File Formats | Adobe PostScript3, PDF, APPE Ver. 6.2, PCL5c/6 |
| Image Processing Technology | S.E.A.D.X图像处理技术 |
| Vacuum Long Paper Feeder | 支持900mm长纸 |
| Color Stability | Simitri V碳粉,低温定影 |
