8GFC SFP+ SW 850nm 300m Optical Transceiver GPP-858G-SRC
The 8GFC SFP+ SW 850nm 300m Optical Transceiver is designed for transmitting and receiving optical data over multimode optical fibers, providing high performance and reliability for fiber channel applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Fiber Type | 62.5μm MMF, 50μm MMF |
| Minimum Modal Bandwidth | 160MHz·km, 200MHz·km, 400MHz·km, 500MHz·km, 2000MHz·km |
| Operating Range | 2-26m, 2-33m, 2-66m, 2-82m, 2-300m |
| Data Rate | 8.5Gbps |
| Power Consumption | 800mW |
| Power Supply Voltage | +3.6V |
| Storage Temperature | -40~85°C |
| Operating Case Temperature | 0~70°C |
| Relative Humidity | 5~95% |
| Recommended Power Supply Voltage | 3.135~3.465V |
| Recommended Operating Case Temperature | -40~85°C |
| Low Speed Characteristics Power Consumption | 0~0.8W |
| Transmitter Center Wavelength | 840~860nm |
| Transmitter Average Optical Power | -6.5~-1dBm |
| Transmitter Extinction Ratio | 3dB |
| Transmitter Dispersion Penalty | 3.9dB |
| Transmitter Relative Intensity Noise | -128dB/Hz |
| Transmitter Optical Return Loss Tolerance | 12dB |
| Receiver Center Wavelength | 840~860nm |
| Receiver Sensitivity | -11.1dBm |
| Receiver Stressed Sensitivity in OMA | -7.5dBm |
| Receiver Loss Function | -30~-1dBm |
| Receiver Reflectance | -12dB |
| Transmitter Single Ended Output Voltage Tolerance | -0.3~4.0V |
| Transmitter Common Mode Voltage Tolerance | 15mV |
| Transmitter Input Data Voltage | 180mV |
| Transmitter Data Dependent Input Jitter | 0.10UI |
| Transmitter Data Input Total Jitter | 0.28UI |
| Receiver Single Ended Output Voltage Tolerance | -0.3~4.0V |
| Receiver Output Data Voltage | 300~850mV |
| Receiver Output Rise and Fall Time | 0.7ns |
| Receiver Total Jitter | 0.70UI |
| Receiver Deterministic Jitter | 0.42UI |
