GP-315G-L1TI
The GP-315G-L1TI is a high-performance SFP transceiver designed for single-mode fiber applications. It supports data rates up to 4.9Gbps and a transmission distance of 10km, making it ideal for CPRI and other optical links.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Data Rate | 4.25-4.9Gbps |
| Transmission Distance | 10km |
| Operating Case Temperature | -40°C~+85°C |
| Storage Temperature | -40°C~+85°C |
| Relative Humidity | 5%-95% |
| Power Supply Voltage | 3.135-3.465V |
| Power Consumption | 800mW |
| Transmitter Wavelength Range | 1260-1355nm |
| Transmitter Power Range | -5dBm to -1dBm |
| Extinction Ratio | ≥5dB |
| Optical Return Loss Tolerance | ≥12dB |
| Receiver Wavelength Range | 1260-1355nm |
| Receiver Sensitivity | -16dBm to -14dBm |
| Receiver Reflectance | ≤-20dB |
| Single Ended Output Voltage Tolerance | -0.3V to +4.0V |
| Common Mode Voltage Tolerance | 15mV |
| Rx Output Diff Voltage | 600-850mV |
| Rx Output Rise and Fall Time | 30ps (20%-80%) |
| Digital Diagnostic Temperature Accuracy | -3°C to +3°C |
| Digital Diagnostic TX Optical Power Accuracy | -3dB to +3dB |
| Digital Diagnostic RX Optical Power Accuracy | -3dB to +3dB |
| Digital Diagnostic Supply Voltage Accuracy | -0.08V to +0.08V |
| Digital Diagnostic Bias Current Monitor Accuracy | -10% to +10% |
| Dynamic Range Temperature | -40°C to +85°C |
| Dynamic Range TX Optical Power | -7dBm to +1dBm |
| Dynamic Range RX Optical Power | -16dBm to -1dBm |
| Dynamic Range Supply Voltage | 3.0V to 3.6V |
| Dynamic Range Bias Current Monitor | 0-40mA |
Applications
Key Features
Datasheet
