UHD Video Optical Transmission
A high-performance solution for transmitting 3G-12G SDI video signals over fiber optics, ensuring high-quality video transmission for UHD applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Transmission Distance | 2km, 20km, 40km, 80km |
| Wavelength | 1310nm, 1550nm, 1271-1611nm (20nm), 1528.77-1563.05nm (100GHz), C-band (50GHz) |
| Optical Interface | LC, Simplex LC, Simplex LC/SC |
| Data Rate | 3Gb/s, 12Gb/s |
| Insertion Loss | ≤4.0dB |
| Max Length | 100m |
Applications
Key Features
Datasheet
