V3 High-Precision All-Round Fusion Splicer
The V3 High-Precision All-Round Fusion Splicer is a cutting-edge device designed for efficient and precise fiber splicing. It features advanced technology, including a patented V-type heating tank and a 5-in-1 heater fixture, ensuring fast and reliable splicing results.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Model | V3 |
| Applicable Fibers | SM(ITU-TG.652), MM(ITU-TG.651), DS(ITU-TG.653), NZ/NZDS(ITU-TG.655), BI(ITU-TG.657) |
| Compatible Fiber/Cable | 0.25-3.0mm/Indoor Cable |
| Cleaved Length | Coating Diameter: 0.125-1mm/Cleaved Length: 8-16mm |
| Splicing Mode | Preset 41 splicing modes, storable 100 modes |
| Typical Splice Loss | SM: ≤0.03dB, MM: ≤0.02dB, DS: ≤0.05dB, NZDS: ≤0.05dB, G.657: ≤0.03dB (ITU-T Standard) |
| Return Loss | ≥60dB |
| Lighting | 3 powerful white LEDs |
| Splicing Time | SM FAST mode: 6s |
| Estimated Splice Loss | Yes |
| Protection Sleeve Length | 20-60mm |
| Heating Tank | Preset 5 kinds of thermal heating tube: 20/30/40/50/60mm, Max 100 modes |
| Heating Time | Optional: 10-90s/Typical Heating Time: ≥20s |
| Results Storage | 10,000 latest records & 200 images |
| Tension Test | 1.5-2.0N |
| Display | 90° bi-directional view, 4.3" high resolution display with touch screen |
| Fiber View & Magnification | X/Y; 400X Magnification |
| Fiber Holder | Multi-function free disassembly fiber clamp |
| Power Supply | 5200mAh battery capacity |
| Battery Capacity | Typical above 400 times (splicing+heating) |
| Operating Methods | Button/Touch Screen |
| Automatic Calibration | Automatic ARC calibration by air pressure and temperature |
| Electrode Life | 3000 ARCs |
| Terminal | Mini USB 2.0 |
| Weight | 2044g (including rubber bumper) |
| Dimension | 142mm×172mm×134mm (W×L×H) |
| Operating Condition | Operating altitude: 0-5000m above sea level, 0-95% relative humidity, -20-50°C, max wind 15m/s |
| Storage Condition | 0-95% relative humidity, Extreme storage: -40-80°C; battery storage: -20-30°C |
