FLS-5834B
The FLS-5834B is a modulated, polarized, high-power LED that can also be used as a broadband source for DWDM channel and component testing.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength (nm) | 1580±10 |
| Output Power (dBm) | 7 |
| Peak Spectral Density (dBm/nm) | ≥-12.5 |
| Power stability (10 minutes) (dB) | ≤0.075 |
| Modulation frequency (MHz) | 100 |
| Size (HxWxD) | 194mmx99mmx40mm (7.6inx3.9inx1.6in) |
| Weight | 0.5kg (1.1lb) |
| Temperature Operating | 0°C to 40°C (32°F to 104°F) |
| Temperature Storage | -20°C to 50°C (-4°F to 122°F) |
| Relative Humidity | 0% to 90% non-condensing |
Applications
Key Features
Datasheet
