HSGQ-X100W3

PON Interface: 1×SC/APC, GPON/EPON auto-adaptive (XPON) Standards: ITU-T G.984.x (GPON); IEEE 802.3ah (EPON) Downstream Rate: 2.488Gbps (GPON); 1.25Gbps (EPON)

A white desktop FTTH optical network terminal from C-Data with four external high-gain antennas. The front-panel status LEDs (PWR, PON, LOS, INT, LAN1~LAN4, TEL, CATV, 2.4G and 5G/WiFi) indicate a GPON/EPON (XPON) ONU that integrates 4 Gigabit Ethernet ports, 1 POTS voice port, an RF CATV output and dual-band 2.4GHz/5GHz WiFi, delivering triple-play broadband, IPTV/CATV and VoIP services over a single fiber.

Number of External Antennas: 4 Ethernet LAN Ports: 4×RJ45 (10/100/1000Mbps, yellow) POTS Voice Port: 1×RJ11

Based on the product image, this device is a desktop FTTH optical network terminal (ONU/ONT) integrating broadband data, VoIP voice and CATV video services in a single unit. The rear panel is equipped with four yellow RJ45 Ethernet LAN ports, one RJ11 telephone (POTS) port, one F-type coaxial RF output for cable TV (CATV), one DC power jack and a reset button. Four external high-gain antennas provide dual-band wireless coverage, making the unit a typical triple-play gateway for fiber-to-the-home deployments. The white plastic enclosure with bottom ventilation slots supports desktop placement and long-term stable operation. Detailed optical and electrical parameters should be confirmed with the manufacturer's official datasheet.

Model: FT1004B Device Type: Remote GPON OLT Number of PON Ports: 4

The C-DATA FT1004B is a compact remote GPON Optical Line Terminal (OLT) in a 1U rack-mount chassis. It provides 4 GPON SFP ports compliant with ITU-T G.984.x standards, a 10GE uplink port for high-capacity backhaul, and a front-panel LCD status monitor with comprehensive LED indicators. Equipped with a console port and reset button, it supports flexible local and remote management, making it ideal for FTTH/FTTB fiber access and edge/remote node deployments.

Product Type: Fiber Optic Terminal Box / Optical Cable Terminal Enclosure Housing Material: Cold-rolled steel (typical for this enclosure type) Surface Treatment: Electrostatic powder coating

The product shown is a fiber optic terminal box (optical cable terminal enclosure) with a rectangular cold-rolled steel housing and a removable top cover fixed by screws. The white electrostatic powder-coated enclosure is designed to protect fiber splicing, termination and distribution points, providing a clean and compact solution for managing incoming optical cables and pigtails in FTTH, LAN and telecom wiring environments. The flat-lid structure allows easy access for installation, fusion splicing and maintenance, while the sealed metal body protects internal fiber connections from dust and external damage. Ports/adapter openings and internal accessories are configured according to the specific model. Detailed parameters such as exact dimensions and port count should be confirmed with the supplier, as they are not shown in the provided material.

Supported Optical Network Type: PON/POF Optical Interface Type: SC (Blue) Number of Optical Ports: 1

The PON/POF Optical Terminal is a compact fiber optic communication device designed to terminate PON (Passive Optical Network) lines and support POF (Plastic Optical Fiber) connectivity. Based on the product image, the front panel is equipped with a blue SC-type optical port labeled 'PON/POF' and a DC barrel jack labeled 'PWR' for power input. The top cover carries LED status indicators for power and link monitoring. The unit is housed in a sturdy white metal enclosure with four front-panel fixing screws and bottom mounting tabs, allowing easy wall or cabinet installation for FTTH and in-building optical distribution applications.
