Multi Channel LVDT System
Soway's data acquisition system offers powerful data analysis capabilities, processing sensor signals through USB interfaces for precise output. It features modular design and seamless data transmission, making it ideal for various applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Number of Channels | Up to 32 |
| Supply Voltage | 220VAC or 24VDC |
| Input Signal | 0-5V |
| Output Signal | USB interface |
| A/D Resolution | 16-bit |
| AD Conversion Time | 1.5μs |
| System Accuracy | 0.01mm |
| System Stability | 0.01% |
| Storage Temperature | -20°C to 70°C |
| Operating Temperature | -20°C to 50°C |
| Dimensions | 280x260x120mm |
