SWD Series Capacitive Flow Meter
The SWD series capacitive flow meter utilizes capacitive principles to measure liquid flow (e.g., automotive oil). It features dynamic flow monitoring, high precision, and resistance to oil contamination. The device supports RS485 output with Modbus protocol and GPS connection, making it widely applicable for flow measurement and vehicle oil monitoring.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Power Supply | 3.8-5.5VDCVDC |
| Output Signal | Integrated circuit |
| Load Current | 20.0(max)mA |
| Temperature Signal | T=(Vout-0.5)/0.01℃(Vout=0.5VDC at 0℃) |
| Range Ratio | 1:45 (SWD01), 1:40 (SWD02) |
| Flow Rinse Volume | 1.42ml (SWD01), 2.94ml (SWD02) |
| Flow Accuracy | ±1% |
| Temperature Accuracy | <±0.25% |
| Installation Position | Push-fit installation |
| Viscosity Range | Minimum 1/3, Maximum 3000, CST |
