10G SFP LR CWDM(10Km) OSFP-10CWDM10
This enhanced small-form-factor pluggable (SFP) fiber transceiver includes digital diagnostic monitoring (DDM). It complies with Ethernet standards and is ideal for 10Gbps data communications. DDM alarms and warnings are integrated through an I2C serial interface under the SFF-8472 multisource agreement (MSA), version 10.4. The transceiver supports data rates from 155Mbps to 1.25Gbps and provides a solution for 1310nm transmission over up to 20 kilometers of single-mode fiber. Subwatt consumption and excellent EMI performance support high port density. It is RoHS compliant and designed and tested to industry safety standards, and is a Class I laser product under US FDA/CDRH and international IEC-60825 standards. The SFP LR connects to a standard 20-contact SFP connector for hot swapping, allowing configuration changes or maintenance by replacing the transceiver without switching off the host. Transmitter and receiver DATA interfaces are internally AC-coupled. An LV-TTL transmitter-disable input and loss-of-signal (LOS) output are also provided. A bail latch permits easy module removal and complies with the SFP MSA. A single +3.3V supply powers operation at case temperatures of 0°C to +70°C commercially or -40°C to +85°C industrially. The metal case protects against electromagnetic interference.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Emission wavelength [CW] | DM |
| Specification | 10Km |
Key Features
Datasheet
Please provide your email to download the datasheet.
Invalid email format. Please try again.
