This product is a specialized optical device designed for precision applications, featuring advanced optical engineering and robust construction.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Outer Diameter | Ø156±0.10 |
| Mounting Hole Diameter | Ø5.5 |
| Number of Mounting Holes | 6 |
| Flange Outer Diameter | Ø60±0.10 |
| Total Length | 150.8 |
| Optical Axis Height | 17 |
| Flange Thickness | 20 |
