Type 8131 Radar Filling Level Meter
The Type 8131 is a non-contact radar level meter designed for continuous level measurement of liquids and bulk solids. It is ideal for applications such as water treatment, storage tanks, and small silos, offering excellent radar signal focusing and high measurement dynamics.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Material | PBT (polyester), PVDF |
| Non-wetted parts | Cover: PBT (polyester), Housing: PBT (polyester), Seal: Silicone O-ring, Cable gland seal: EPDM |
| Wetted parts | Process connection: PVDF, Antenna: PVDF, Seal: FKM or EPDM depending on variant |
| Display | LCD with graphical support |
| Weight | Approx. 0.7kg |
| Measuring Range | 0...10m or 0...20m depending on application |
| Beam Angle | 8° |
| Damping | 0...999s, adjustable |
| Operating Mode | Mode 1: EU and other countries, Mode 2: Brazil, Japan, South Korea, Taiwan, Thailand, Mode 3: India, Malaysia, Mode 4: Kazakhstan, Russia |
| Blocking Distance | Operating mode 1, 2, 4: 0mm, Operating mode 3: 250mm |
| Measuring frequency | W-Band (80GHz technology) |
| Measuring Cycle Time | ≤250ms |
| Step Response Time | ≤3s |
| Temperature drift | <0.03%/10K or max. 0.3% related to the 16.7mA span |
| Operating voltage | 12...35VDC |
| Output Signal Range | 4...20mA or 3.8...20.5mA (HART) |
| Signal Resolution | 0.3μA |
| Output Current | Max. 22mA |
| Fault Signal | mA value unchanged, ≥21mA or ≤3.6mA (adjustable) |
| Medium Temperature | Variant 0...10m: -40...+60°C, Variant 0...20m: -40...+80°C |
| Process Pressure | 1...3bar (14.5...43.5psig) |
| Process Connection | G, NPT or R1½ thread |
| Wireless communication | Bluetooth radio V5.0, downward compatible with V4.0 |
| Frequency | 2.402...2.480GHz |
| Emitted power | Max. +2.2dBm |
| Typical effective range | 25m (82ft) |
