SONASCREEN 2 for instrument
Experience a new generation;
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Dimensions | 31 x 16 x 5.5 cm (12.2 x 6.3 x 2.2 inches); acoustic, optical, FFT and spectrum Figure |
| Weight | 1.5 kg (3.3 pounds) |
| Ingress Protection Rating | IP54 |
| Operating Temperature | - 20°C to 50°C (4°F to 122°F); sound |
| Display Size | 7 inch/15 cm x 9.4 cm |
| Interface | 3 Zoom Modes: Closed, Automatic, Smart |
| Wavelength | Long-wave infrared, 8-14um |
| Resolution | 160 x 120 |
| Sensor | Frequency; 8.7HZ |
| Thermal Sensitivity | <50mK |
| Frequency Range | From 1Hz to 100 kHz |
| Temperature Measurement Range | -10°C to 400°C (room temperature) |
| Sampling Frequency | 200 kHz |
| Resolution | Twenty-four |
| detection range | Up 150 m |
| Type | numbers;mission 308782 K0 C02 |
| Resolution | 640 × 480 （56 fps） |
| Input | 19 V, power adapter |
