LSP-LRS-0810A 8km Laser Rangefinder Module
1535nm Laser, Weight, 8km (2.3*2.3m)
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Divergence Angle | ≤0.3mrad |
| Voltage | DC9-16V ( ) |
| Main functions | The main functions of the laser ranging module are: a) single ranging and continuous ranging; b) distance gating, front and rear target indication; c) self-test function |
| Scope of work | "≥8,000m" (visibility under full-view conditions > 12km; vehicle target: 2.32.3m; diffuse reflectance ≥ 30%; humidity ≤80%)" |
| Continuous ranging frequency | 1Hz-10Hz (adjustable) |
| Accuracy rate | ≥98% |
| interface | RS422 |
| Start time | ≤5s |
