PLS16620APO
The PLS16620APO is a high-precision optical lens designed for industrial and scientific imaging applications. It offers excellent optical performance with minimal distortion and high resolution.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Magnification | 6.2X(5.6X-6.9X) |
| Working Distance | 79.36 |
| Image Distance | 712.18 |
| Conjugate Distance | 910.03 |
| Flange Focal Distance | 742.18 |
| Max Image Circle | Φ88 |
| F/# | 1.58 |
| NA | 0.17 |
| EFL | 116.7 |
| ENP Diameter | 73.8 |
Applications
Key Features
Datasheet
